Digital Image Processing

Homework 5, Due 2016/6/8

Problem 1

Ideal lowpass filter

Write a program to filter using ILPFs and obtain the results on Page 272, Figure 4.42.




Problem 2

Notch reject filter

Use the Butterworth notch reject filter to remove the Moire pattern on Page 296, Figure 4.64.




Problem 3

Contraharmonic mean filter

(a) Apply a 3×3 contraharmonic filter of order 1.5 to Fig0508(a)(circuit-board-pepper-prob-pt1).bmp.

(b) Apply a 3×3 contraharmonic filter of order -1.5 to Fig0508(b)(circuit-board-salt-prob-pt1).bmp





Upload your homework to e起來-高大教學平台 .
